Запчасти Komatsu PC200LL-8 A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6754-11-1012

HEAD, CYLINDER

|$1

6754-41-4200

KIT, EXHAUST VALVE

1

6744-11-1020

COLLET, VALVE

2

NSS

VALVE, EXHAUST

|$4

6754-41-4100

KIT, INTAKE VALVE

3

6744-11-1020

COLLET, VALVE

4

NSS

VALVE, INTAKE

5

6754-41-4540

SEAL, VALVE STEM

6

6754-41-4540

SEAL, VALVE STEM

7

6754-41-4430

SPRING, VALVE

8

6754-41-4510

RETAINER, VALVE SPRING

|$11

NSS

HEAD, CYLINDER

9

6736-21-1820

PLUG, EXPANSION

10

6735-21-5530

PLUG, EXPANSION

11

NSS

HEAD, CYLINDER

12

6754-11-1150

PLUG, EXPANSION

13

6744-11-1070

PLUG, EXPANSION

14

6754-11-1160

PLUG, EXPANSION

15

6754-11-1170

INSERT, VALVE (STD)

15

1317 540 H1

INSERT, VALVE (0.127 MM OVERSIZE)

15

1317 541 H1

INSERT, VALVE (0.254 MM OVERSIZE)

15

1317 542 H1

INSERT, VALVE (0.508 MM OVERSIZE)

16

6754-11-1180

INSERT, VALVE (STD)

16

1317 543 H1

INSERT, VALVE (0.127 MM OVERSIZE)

16

1317 544 H1

INSERT, VALVE (0.254 MM OVERSIZE)

16

1317 545 H1

INSERT, VALVE (0.508 MM OVERSIZE)

17

6754-11-1811

GASKET, CYLINDER HEAD

18

6754-11-1610

BOLT
