Запчасти Komatsu PC200LL-7L ОСНОВН. КЛАПАН (LS DIVIDER КЛАПАН) ГИДРАВЛИКА

|$0

723-47-20701

VALVE ASS'Y,(SEE FIG. H0120-51A0)

|$1

723-40-66701

VALVE ASS'Y

1

CASE

2

SEAT

3

SEAT

4

708-8H-11530

PLUG

5

07002-11423

O-RING

6

SEAT

7

BALL

8

PLUG

|$10

723-40-66601

VALVE ASS'Y

9

CASE

10

SEAT

11

SEAT

12

BALL

13

PLUG

14

01252-61050

BOLT

15

01643-51032

WASHER

|$18

723-40-60101

VALVE ASS'Y

16

SLEEVE

17

VALVE

18

PISTON

19

PISTON

20

SPRING

21

07000-12020

O-RING

22

07001-02020

RING,BACK-UP

23

709-25-11390

O-RING

24

SPRING

25

PLUG

26

O-RING

27

SEAL

28

O-RING
