Запчасти Komatsu PC200LL-7L МОТОР ХОДА (МОТОР И ТОРМОЗ.) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

708-8F-00192

MOTOR ASS'Y,(SEE FIG.P1210-03A0)

1

708-8F-32121

SHAFT

2

708-8F-12151

BEARING

3

708-7L-12140

BEARING

4

708-7L-05010

SPACER KIT

|$6

SPACER¤ 1.5MM

|$7

SPACER¤ 1.6MM

|$8

SPACER¤ 1.7MM

|$9

SPACER¤ 1.8MM

|$10

SPACER¤ 1.9MM

|$11

SPACER¤ 2.0MM

5

706-7G-11291

SEAL,OIL

6

708-8F-12230

SPACER¤ 3.2MM

7

04065-07225

RING

8

BLOCK,CYLINDER

9

PLATE,VALVE

10

PIN

11

708-8F-33360

PIN

12

708-7L-13140

SEAT

13

708-8F-33160

SPRING

14

04065-04818

RING,SNAP

15

708-8F-33350

GUIDE,RETAINER

16

708-2L-33350

RETAINER,SHOE

17

708-8F-33310

PISTON SUB ASS'Y

18

708-8F-33471

CAM,ROCKER

19

708-8F-33710

BALL,RETAINER

20

708-8F-34141

PISTON

21

708-8F-34150

SPRING

22

708-8F-35110

PLATE

23

708-8F-35130

PLATE

24

708-8F-35120

DISC

25

708-8F-35140

PISTON,BRAKE

26

708-8F-35160

O-RING

27

708-8F-35170

RING,BACK-UP

28

708-8F-35180

O-RING

29

708-8F-35190

RING,BACK-UP

30

708-8F-35150

SPRING

31

04025-00324

PIN,SPRING
