Запчасти Komatsu PC200LL-7L КЛАПАН PPC(ДЛЯ ХОДА) (/) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$1

702-16-04160

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-72570

CASE

11

LEVER

12

SHAFT

13

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

04025-00432

PIN,SPRING

18

702-16-54430

BUSHING

19

702-16-54331

WASHER¤ 1.60MM

|$22

702-16-54341

WASHER¤ 1.30MM

|$23

702-16-54351

WASHER¤ 1.00MM

20

702-16-54280

SEAL,DUST

21

702-16-72500

DAMPER ASS'Y

22

01252-60525

BOLT

23

702-16-54511

PLATE

24

04025-00420

PIN,SPRING

25

702-16-54520

LEVER

26

01224-40612

SCREW
