Запчасти Komatsu PC200LL-7L КАБИНА (ПЕРЕДН. ВЕРХН. ОКНА)(№A8-A877) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-54-01172

CAB ASS'Y,(SEE FIG. K0210-01B0)

|$1

20Y-54-01132

WINDOW ASS'Y

1

FRAME¤ FRONT,WINDOW

2

20Y-54-51522

GLASS,FRONT

3

20Y-54-51531

SEAL,FRONT WINDOW

4

20Y-54-51551

SEAL,FRONT¤ LOWER

5

22B-54-15411

LOCK ASS'Y,L.H.

6

22B-54-15440

CASE,L.H.

7

22B-54-15470

KNOB,L.H.

8

22B-54-15421

LOCK ASS'Y,R.H.

9

22B-54-15450

CASE,R.H.

10

22B-54-15480

KNOB,R.H.

11

01435-40812

BOLT

12

01435-40812

BOLT

13

20Y-54-52621

ROLLER

14

20Y-54-52681

ROLLER

15

20Y-54-52691

PIN,UNDER¤ L.H.

16

20Y-54-14590

HANDLE

17

01023-10616

SCREW

18

20Y-54-52632

BRACKET

19

20Y-54-52642

BRACKET

20

01245-00616

SCREW

21

01643-70623

WASHER

22

20Y-54-51670

STOPPER

23

20Y-54-51680

STOPPER

24

01252-80616

BOLT

25

01643-70623

WASHER

26

20Y-54-51633

BLOCK,UNDER¤ L.H.

27

20Y-54-52192

BLOCK,UNDER¤ R.H.

28

01252-80620

BOLT

29

01641-50608

WASHER

30

20Y-54-51652

BLOCK,L.H.

31

20Y-54-52282

BLOCK,L.H.

32

20Y-54-53531

COVER

33

20Y-54-51663

BLOCK,CORNER¤ R.H.

34

20Y-54-52940

PLATE

35

20Y-54-53541

COVER

36

22B-54-15621

STOPPER

37

01224-70612

SCREW

38

01252-80616

BOLT

39

01641-50608

WASHER

40

22B-54-15432

STRIKER,SASH

41

01435-40616

BOLT

42

21J-06-12440

SWITCH

43

01583-11811

NUT

44

20Y-54-11611

STOPPER

45

01580-11008

NUT

46

20Y-54-52491

PLATE

47

01435-40612

BOLT

48

20Y-54-51622

STRIKER

49

20Y-54-51541

TRIM,FRONT

50

20Y-54-51591

SPRING ASS'Y

51

01435-00616

BOLT

52

20Y-54-51640

HOLDER

53

20Y-54-51420

SEAL
