Запчасти Komatsu PC200LL-6 FIG. H-A ОСНОВН. КЛАПАН - КОРПУС ГИДРАВЛИКА

1

20Y-62-27413

BRACKET, MAIN CONTROL VALVE

2

01010-81655

BOLT

3

01643-31645

WASHER

4

01010-81650

BOLT

5

01643-31645

WASHER

6

20Y-62-27192

BRACKET

7

01010-81230

BOLT

8

01643-31232

WASHER, PLAIN M12

9

20Y-62-21264

BRACKET

10

01010-81235

BOLT

11

01643-31232

WASHER, PLAIN M12

12

702-21-09147

VALVE ASSEMBLY, MERGE DIVIDER

13

21T-09-11460

O-RING

14

708-27-12560

BOLT

15

01643-51032

WASHER, PLAIN

16

07371-31049

FLANGE, SPLIT

17

07372-21035

BOLT

18

01643-51032

WASHER, PLAIN

19

21Y-62-17810

ELBOW ASSEMBLY

20

07002-12434

O-RING

21

07235-10210

ELBOW

22

07002-11423

O-RING

23

07235-10210

ELBOW

24

07002-11423

O-RING

25

07371-31049

FLANGE

26

07372-21035

BOLT

27

01643-51032

WASHER

|$27

20Y-62-27241

HOSE ASSEMBLY

28

203-62-52280

HOSE

29

20Y-62-22881

HOSE

30

20Y-62-22820

BAND, BLUE

31

07096-00221

HOSE

32

20Y-62-22810

BAND, YELLOW

33

04434-52712

CLIP

34

01010-81225

BOLT

35

01643-31232

WASHER

36

08034-20519

BAND

37

04434-51512

CLIP
