Запчасти Komatsu PC200LL-6 FIG. H-A ГИДР. БАК. ГИДРАВЛИКА

|$0

20Y-60-00064

TANK ASSEMBLY, HYDRAULIC

1

20Y-60-22614

KIT, HYDRAULIC TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

07230-20628

NIPPLE

7

07002-02434

O-RING

8

07236-10522

ELBOW

9

07002-02434

O-RING

10

07235-10315

ELBOW

11

07002-02034

O-RING

12

07236-10315

ELBOW

13

07002-02034

O-RING

14

07236-10210

ELBOW

15

07002-11423

O-RING

16

20Y-60-21510

ELEMENT

17

07069-25400

STRAINER

18

07069-05400

VALVE ASSEMBLY

19

07069-34075

SPRING

20

20Y-60-22530

COVER

21

07000-05180

O-RING

22

01010-81230

BOLT

23

01643-31232

WASHER

24

7861-92-4210

SENSOR

25

01252-40612

BOLT

26

01641-20608

WASHER

|$27

20Y-60-22550

STRAINER ASSEMBLY

27

207-60-61150

ROD ASSEMBLY

28

20Y-60-21320

HOLDER

29

12R-60-11230

SPRING

30

20Y-60-21311

STRAINER, HYDRAULIC TANK

31

NSS

COVER

32

07000-05180

O-RING

33

01010-81225

BOLT

34

01643-31232

WASHER

35

20Y-60-21440

CAP

36

20Y-60-21460

NECK, FILLER

37

20Y-60-21340

GASKET

38

01252-70516

SCREW

39

01601-20513

WASHER

40

07285-00155

CLAMP

41

20Y-60-21190

TUBE

42

01010-81635

BOLT

43

01643-31645

WASHER
