Запчасти Komatsu PC200LL-6 FIG. A-AA ПРИВОД ВЕНТИЛЯТОРА ДВИГАТЕЛЬ

1

6216-84-6270

WASHER (M12)

2

6731-61-4240

BELT, V

3

6731-61-4250

BOLT (M10-1.50x25)

4

6731-61-4260

NUT (M10-1.50 Thd)

5

6736-21-3210

BOLT (M8-1.25x50)

6

6736-81-8730

BOLT (M8-1.25x80)

|$6

6732-61-3120

SUPPORT, FAN

7

6732-61-3450

RING, RETAINING

8

6732-61-3440

BOLT (M10-1.50x70)

9

6732-61-3420

BEARING, BALL

10

6732-61-3410

HUB, FAN

11

NSS

SUPPORT, FAN

12

6732-61-3430

RETAINER, FAN HUB

13

6732-61-3750

PULLEY, FAN

14

6731-61-4270

BOLT

15

6731-61-4280

BOLT (M10-1.50x30)

16

6736-21-5310

BOLT (M8-1.25x16)

17

6732-61-3170

BOLT (M8-1.25x40)

18

6207-61-3280

PULLEY, FAN

19

6735-81-6310

PLATE, CLAMPING

20

6222-83-6620

BRACKET, BELT TENSIONER

21

6735-81-6410

BRACKET, ADJUSTING LINK

|$22

6735-61-3300

SUPPORT, FAN

22

6731-61-3310

RING, RETAINING

23

NSS

SUPPORT, FAN

24

NSS

BOSS

25

6735-61-3320

SHAFT, FAN HUB

26

06000-06205

BEARING, BALL

27

06037-06305

BEARING, BALL

28

07046-22216

COVER, ACCESS HOLE

|$30

6735-81-6200

SUPPORT, FAN

29

6735-81-6220

PULLEY, IDLER

30

6206-81-6240

SHAFT, IDLER

31

6206-81-6250

SPACER, MOUNTING

32

6735-81-6210

SUPPORT, BELT TENSIONER

33

6136-61-1340

BEARING, BALL

34

06000-06004

BEARING, BALL

35

07046-44516

COVER, ACCESS HOLE

36

6731-61-3440

RING, RETAINING

37

6151-81-4340

BOLT (M10-1.50x110)

38

6204-11-3830

WASHER, PLAIN

39

6211-11-9790

SPACER, MOUNTING
