Запчасти Komatsu PC200LC-8E0 УПРАВЛЯЮЩ. КЛАПАН, ВНУТР. ЧАСТИ (/7) (№8-) УПРАВЛЯЮЩ. КЛАПАН

|$0

723-46-23103

Valve Assembly

|$1

723-40-72100

Valve Assembly

1

Body, Valve

2

Spool

3

723-40-72800

Plate Assembly

4

702-21-60500

Valve, Pilot

5

723-11-19960

O-ring

6

702-21-54910

O-ring

7

723-46-15111

Case

8

07430-71380

O-ring

9

723-40-71330

Retainer

10

723-40-71340

Spring

11

723-40-71350

Retainer

12

01252-60816

Bolt, Hexagon Socket Head

13

723-40-71870

Union

14

02896-11008

O-ring

15

07002-11423

O-ring

16

07040-11409

Plug

17

07002-11423

O-ring

18

01252-60855

Bolt, Hexagon Socket Head

19

01252-60635

Bolt, Hexagon Socket Head

20

Spool Assembly

21

723-40-71850

Spring

22

723-46-18720

O-ring

23

Spool

24

723-40-71390

Spring

25

723-46-18720

O-ring

25

723-40-71900

Valve Assembly

26

Valve, Relief

27

702-16-53920

O-ring

28

07002-11623

O-ring

29

Block

30

Spool

31

Spring

32

702-21-55620

Plug

33

07002-11423

O-ring

34

702-21-55710

Seat

35

702-21-55720

Spring

36

04260-00793

Ball

37

07000-11009

O-ring

38

Plug
