Запчасти Komatsu PC200LC-8E0 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№8-) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

20Y-27-00500

Final Drive Assembly

|$1

708-8F-00250

Motor Assembly

|$2

708-8F-04681

Case Subassembly

1

Case, Motor

2

Plug

|$5

708-8F-04270

Cover Subassembly, End

3

Cover, End

4

Spool

5

Plug

6

Plug

7

Spool

8

708-8F-34220

Spring

9

708-8H-11530

Plug

10

07002-11423

O-ring

11

20B-27-11210

Bleeder

12

702-73-02112

Valve Assembly, Relief

13

708-8F-36611

Spring

14

Ring

15

708-8H-36121

Spring

16

708-8F-36311

Cover

17

07000-13040

O-ring

18

700-93-11320

O-ring

19

07000-11009

O-ring

20

01252-61235

Bolt, Hexagon Socket Head

21

708-8F-34120

Valve

22

722-10-91130

Spring

23

708-8F-34110

Plug

24

07002-11823

O-ring

25

708-8E-16180

Valve

26

708-8F-31650

Plug

27

07000-11006

O-ring

28

07001-01006

Ring, Back-up

29

07002-11223

O-ring

30

708-8F-31610

O-ring

31

07000-11009

O-ring

32

04020-01228

Pin, Dowel

33

708-8F-31210

Bolt
