Запчасти Komatsu PC200LC-8E0 КАБИНА COVER ЧАСТИ КОРПУСА

1

20Y-54-76490

COVER

1

COVER

2

20Y-54-76230

SHEET

3

20Y-00-42140

PLATE

4

01010-81230

BOLT

5

175-54-34170

WASHER

6

01010-81230

BOLT

7

01643-31232

WASHER

8

20Y-54-61990

COLLAR

9

20Y-54-61790

PLATE

|$17

20Y-54-73741

COVER

10

COVER

11

20Y-54-73730

SHEET

12

20Y-00-42140

PLATE

13

20Y-54-71723

COVER

14

20Y-54-25852

LOCK (WELDED)

15

20Y-54-73190

LOCK ASS'Y

16

20Y-54-75910

LEVER

17

20Y-54-75930

BRACKET

18

20Y-54-75920

LEVER

19

21K-54-26351

SPRING

20

20X-54-21460

SPRING

21

04205-11038

PIN

22

04050-13020

PIN

23

01010-81025

BOLT

24

01643-31032

WASHER

25

20Y-54-27182

BRACKET

26

01010-81025

BOLT

27

01643-31032

WASHER

28

205-54-68440

PLATE

29

01224-40616

SCREW

30

01010-81230

BOLT

31

01643-31232

WASHER

32

01010-81230

BOLT

33

175-54-34170

WASHER

34

01010-81230

BOLT

35

01643-31232

WASHER

36

20Y-54-74441

COVER

37

205-54-32280

NET

38

01010-D1030

BOLT

39

01643-71032

WASHER

40

20Y-54-71731

COVER

41

20Y-54-71172

FRAME

42

01010-81230

BOLT

43

175-54-34170

WASHER

44

01010-81230

BOLT

45

01643-31232

WASHER
