Запчасти Komatsu PC200LC-8 H-A ГИДР. БАК. ГИДРАВЛИКА

1

20Y-60-41114

TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

07044-12412

PLUG, WITH MAGNET

5

07002-12434

O-RING

6

02781-00628

UNION

7

02896-11018

O-RING

8

07002-12434

O-RING

9

02782-10522

ELBOW

10

02896-11015

O-RING

11

07002-12434

O-RING

12

02782-10315

ELBOW

13

02896-11009

O-RING

14

07002-12034

O-RING

15

02782-10311

ELBOW

16

02896-11009

O-RING

17

07002-11423

O-RING

18

207-60-71182

ELEMENT

19

20Y-60-31140

STRAINER

20

20Y-60-31131

VALVE ASSEMBLY

21

20Y-60-21240

SPRING

22

22U-60-21232

COVER

23

07000-15195

O-RING

24

01010-81230

BOLT

25

01643-31232

WASHER

|$25

20Y-60-31171

STRAINER ASSEMBLY

26

207-60-61150

ROD ASSEMBLY

27

20Y-60-21320

HOLDER

28

12R-60-11230

SPRING

29

22B-60-11160

STRAINER

30

20Y-60-41162

COVER

31

07000-15160

O-RING

32

01010-81230

BOLT

33

01643-31232

WASHER

34

17A-60-11310

CAP ASSEMBLY

35

20Y-60-21470

ELEMENT

36

208-60-71180

NECK

37

20Y-60-21340

GASKET

38

01252-70516

BOLT, HEXAGON SOCKET HEAD

39

01601-20513

WASHER, SPRING

40

07285-00155

CLIP, HOSE

41

07270-61411

TUBE

42

205-00-73360

DECAL, HYDRAULIC GAUGE

43

01010-81635

BOLT

44

01643-31645

WASHER
