Запчасти Komatsu PC200LC-8 A-AC ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

|$1

NSS

TURBOCHARGER

1

NSS

BAFFLE, TURBOCHARGER NOISE

2

1304 920 H1

PLATE, CLAMPING

3

6736-81-8370

BEARING, TURBOCHARGER

4

6731-82-8210

NUT, LOCK

5

6736-81-8480

SCREW, DRIVE

6

6736-81-8430

SHIELD, TURBOCHARGER HEAT

7

6736-81-8280

SHAFT & WHEEL

8

6733-81-8360

RING, RETAINING

9

6736-81-8470

DATAPLATE

10

6733-81-8330

BAFFLE, OIL

11

6733-81-8460

SEAL, O-RING

12

6733-81-8270

PLATE, OIL SEAL

13

6733-81-8260

SLINGER, OIL

14

6743-82-8140

RING, RETAINING

15

6735-81-8620

COLLAR, THRUST

16

6733-81-8480

PIN, ROLL

17

NSS

HOUSING, TURBOCHARGER BEARING

18

6735-81-8310

RING, RETAINING

19

NSS

HOUSING TURBINE

20

NSS

IMPELLER, TURBOCHARGER COMPRESSOR

21

NSS

HOUSING, COMPRESSOR

22

6736-81-8440

SEAL, SPLIT RING

23

6736-81-8320

SEAL, SPLIT RING

24

6736-81-8380

BOLT (M8-1.25x12)

25

6736-81-8360

RING, RETAINING

26

6735-82-8220

BEARING, TURBOCHARGER THRUST
