Запчасти Komatsu PC200LC-8 T-A ЦИЛИНДР СТРЕЛЫЛЕВ. РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0H580

CYLINDER ASSEMBLY, LEFT SIDE

1

707-13-12380

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL, DUST

4

707-58-85430

ROD, PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-12650

CYLINDER HEAD

8

07179-13099

RING, SNAP

9

707-56-85510

SEAL, DUST

10

707-52-90610

BUSHING

11

707-75-85110

RING, SNAP

12

707-51-85030

PACKING

13

07000-15110

O-RING

14

707-35-91220

RING, BACK-UP

15

707-51-85650

RING

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-12851

PISTON

19

707-44-12150

RING, PISTON

20

707-39-12140

RING, WEAR

21

707-44-12911

RING

22

707-71-70800

PLUNGER

23

07000-15075

O-RING

24

707-35-90930

RING, BACK-UP

25

01310-01216

SCREW

26

707-71-34660

COLLAR

27

707-35-91220

RING, BACK-UP

28

07000-15110

O-RING

29

707-86-67720

TUBE

30

20Y-62-24580

TUBE

31

07372-21060

BOLT

32

01643-51032

WASHER

33

07372-21045

BOLT

34

01643-51032

WASHER

35

07000-13030

O-RING

36

707-88-28010

BRACKET

37

707-88-21620

BAND

38

07372-21035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP, PIPE

41

01597-01009

NUT

42

01643-31032

WASHER

43

707-88-33030

CAP

44

07371-30640

FLANGE, SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|$47

707-98-46280

SERVICE KIT, BOOM CYLINDER
