Запчасти Komatsu PC200LC-8 P-A МОТОР ХОДА МОТОР И ТОРМОЗ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

708-8F-32121

SHAFT

2

708-8F-12151

BEARING

3

708-7L-12140

BEARING

4

708-7L-05010

SPACER KIT

|$6

708-7L-12220

SPACER, T = 1.5 MM

|$7

NSS

SPACER, T = 1.6 MM

|$8

708-7L-12240

SPACER, T = 1.7 MM

|$9

NSS

SPACER, T = 1.8 MM

|$10

NSS

SPACER, T = 1.9 MM

|$11

NSS

SPACER, T = 2.0 MM

5

706-7G-11291

SEAL, OIL

6

708-8F-12230

SPACER, T = 3.2 MM

7

04065-07225

RING, SNAP, FOR HOLE SIDE

8

708-8F-33121

BLOCK, CYLINDER

9

708-8F-33230

PLATE, VALVE

10

720-68-19610

PIN

11

708-8F-33360

PIN

12

708-7L-13140

SEAT

13

708-8F-33160

SPRING

14

04065-04818

RING, SNAP

15

708-8F-33350

GUIDE, RETAINER

16

708-2L-33350

RETAINER, SHOE

17

708-8F-33310

PISTON SUBASSEMBLY

18

708-8F-33471

CAM, ROCKER

19

708-8F-33710

BALL, RETAINER

20

708-8F-34141

PISTON

21

708-8F-34150

SPRING

22

708-8F-35110

PLATE

23

708-8F-35130

PLATE

24

708-8F-35120

DISC

25

708-8F-35140

PISTON, BRAKE

26

708-8F-35160

O-RING

27

708-8F-35170

RING, BACK-UP

28

708-8F-35180

O-RING

29

708-8F-35190

RING, BACK-UP

30

708-8F-35150

SPRING

31

04025-00324

PIN, SPRING
