Запчасти Komatsu PC200LC-8 A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6754-11-1012

HEAD, CYLINDER

|$1

6754-41-4200

KIT, EXHAUST VALVE

1

6744-11-1020

COLLET, VALVE

2

NSS

VALVE, EXHAUST

|$4

6754-41-4100

KIT, INTAKE VALVE

3

6744-11-1020

COLLET, VALVE

4

NSS

VALVE, INTAKE

5

6754-41-4540

SEAL, VALVE STEM

6

6754-41-4540

SEAL, VALVE STEM

7

6754-41-4430

SPRING, VALVE

8

6754-41-4510

RETAINER, VALVE SPRING

|$11

NSS

HEAD, CYLINDER

9

6736-21-1820

PLUG, EXPANSION

10

6735-21-5530

PLUG, EXPANSION

11

NSS

HEAD, CYLINDER

12

6754-11-1150

PLUG, EXPANSION

13

6744-11-1070

PLUG, EXPANSION

14

6754-11-1160

PLUG, EXPANSION

15

NSS

INSERT, VALVE (STD)

N/I

1317 540 H1

INSERT, VALVE (0.127 MM OVERSIZE)

N/I

1317 541 H1

INSERT, VALVE (0.254 MM OVERSIZE)

N/I

1317 542 H1

INSERT, VALVE (0.508 MM OVERSIZE)

16

NSS

INSERT, VALVE (STD)

NI/

1317 543 H1

INSERT, VALVE (0.127 MM OVERSIZE)

N/I

1317 544 H1

INSERT, VALVE (0.254 MM OVERSIZE)

N/I

1317 545 H1

INSERT, VALVE (0.508 MM OVERSIZE)

17

6754-11-1811

GASKET, CYLINDER HEAD

18

6754-11-1610

BOLT
