Запчасти Komatsu PC200LC-8 РУКОЯТЬ, ЦИЛИНДР КОВША (№-) РУКОЯТЬ, .8M, ЧАС. СИСТ. СМАЗКИ ТИП, -АКТУАТОР

|$0

707-01-0J080

Cylinder Assembly

1

707-13-12590

Cylinder

2

707-58-85440

Rod, Piston

3

707-76-70651

Bushing

4

07145-00070

Seal, Dust, (Kit : K15)

5

07020-00000

Fitting, Grease

6

707-76-70120

Bushing

7

20Y-70-23220

Seal, Dust, (Kit : K15)

8

07020-00000

Fitting, Grease

9

707-27-12750

Head, Cylinder

10

07179-13099

Ring, Snap

11

707-56-85740

Seal, Dust, (Kit : K15)

12

707-52-90611

Bushing

13

707-51-85030

Packing, Rod, (Kit : K15)

14

707-51-85650

Ring, Buffer, (Kit : K15)

15

07000-15115

O-ring, (Kit : K15)

16

707-35-91250

Ring, Back-up, (Kit : K15)

17

01010-81670

Bolt

18

01643-51645

Washer

19

707-75-85110

Ring, Snap

20

721-36-12030

Piston

21

707-44-12250

Ring, Piston, (Kit : K15)

22

707-39-12560

Ring, Wear, (Kit : K15)

23

707-44-12921

Ring

24

07000-15075

O-ring, (Kit : K15)

25

707-35-90930

Ring, Back-up, (Kit : K15)

26

01310-01216

Screw

27

707-86-67820

Tube

28

07372-21045

Bolt

29

01643-51032

Washer

30

07372-21060

Bolt

31

01643-51032

Washer

32

07000-13030

O-ring, (Kit : K15)

33

707-88-22780

Bracket

34

707-88-21530

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

07283-32738

Clip, Pipe

38

01597-01009

Nut

39

01643-31032

Washer
