Запчасти Komatsu PC200LC-8 ГИДР. БАК. (№-9) ГИДР. БАК., С РУКОЯТЬ CRANE

1

20Y-60-41113

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

07044-12412

Plug

5

07002-12434

O-ring

6

02781-00628

Union

7

02896-11018

O-ring

8

07002-12434

O-ring

9

02782-10315

Elbow

10

02896-11009

O-ring

11

07002-12034

O-ring

12

02782-10311

Elbow

13

02896-11009

O-ring

14

07002-11423

O-ring

15

207-60-71182

Element, Hydraulic Oil Filter

16

20Y-60-31140

Strainer

17

20Y-60-31131

Valve Assembly

18

20Y-60-21240

Spring

19

22U-60-21232

Cover

20

07000-15195

O-ring

21

01010-81230

Bolt

22

01643-31232

Washer

|$22

20Y-60-31171

Strainer Assembly

23

207-60-61150

Rod Assembly

24

20Y-60-21320

Holder

25

12R-60-11230

Spring

26

22B-60-11160

Strainer

27

20Y-60-41162

Cover

28

07000-15160

O-ring

29

01010-81230

Bolt

30

01643-31232

Washer

31

17A-60-11310

Cap Assembly

32

20Y-60-21470

Element

33

208-60-71180

Filler Neck, Filler

34

20Y-60-21340

Gasket

35

01252-70516

Bolt

36

01601-20513

Washer

37

07285-00155

Clip

38

07270-61411

Tube

39

205-00-73360

Plate, Operating

40

01010-81635

Bolt

41

01643-31645

Washer
