Запчасти Komatsu PC200LC-8 ЦИЛИНДР РУКОЯТИ( ЧАС. СИСТЕМА СМАЗКИ) (ДЛЯ ПОДЪЕМА РУКОЯТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

707-01-0S410

CYLINDER ASS'Y,(FINAL COATING)

|$1

707-01-0H600

CYLINDER ASS'Y

1

707-13-13870

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95270

ROD,PISTON

5

707-27-13850

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-75-95030

RING,SNAP

10

707-51-95030

PACKING,ROD (KIT)

11

07000-15125

O-RING (KIT)

12

707-35-91370

RING,BACK-UP (KIT)

13

707-51-95650

RING,BUFFER (KIT)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

707-36-13771

PISTON

17

707-44-13250

RING,PISTON (KIT)

18

707-39-13530

RING,WEAR (KIT)

19

707-44-13920

RING

20

707-71-71010

PLUNGER

21

07000-15085

O-RING (KIT)

22

707-35-90960

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-71-80270

PLUNGER

25

07020-00000

FITTING,GREASE

26

707-71-34980

COLLAR

27

707-35-91370

RING,BACK-UP (KIT)

28

07000-15125

O-RING (KIT)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

|$36

707-98-48610

SERVICE KIT
