Запчасти Komatsu PC200LC-8 МЕХАНИЗМ ПОВОРОТА (МОТОР И MACHINERY) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01170

MOTOR ASS'Y

1

706-7G-01041

MOTOR ASS'Y

1

706-7G-03090

MOTOR SUB ASS'Y

2

22U-26-21280

RING

3

07042-00312

PLUG

4

20Y-26-31120

CASE

5

20Y-26-22331

BEARING

5

20Y-26-22330

BEARING

6

20Y-26-22342

BEARING

6

20Y-26-22340

BEARING

7

206-26-69112

SHAFT

7

206-26-69111

SHAFT

8

20Y-26-22420

SEAL

9

20Y-26-22191

COVER

10

01010-81045

BOLT

11

01643-31032

WASHER

12

07000-15310

O-RING

13

22U-26-21580

CARRIER

14

22U-26-21540

GEAR

15

20G-26-11241

BEARING

16

20Y-27-21240

WASHER

17

20Y-26-22250

PIN

18

20Y-27-21280

PIN

19

20Y-26-21240

PLATE

20

112-32-11211

BOLT

21

22U-26-21551

GEAR

22

20K-22-11190

O-RING

23

01010-81440

BOLT

24

01643-31445

WASHER

25

22U-26-21530

GEAR

26

22U-26-21572

CARRIER

27

22U-26-21520

GEAR

28

20Y-26-21281

BEARING

29

22U-26-21230

WASHER

30

22U-26-21210

PIN

31

04064-03515

RING

32

22U-26-21250

WASHER

33

22U-26-21510

GEAR
