Запчасти Komatsu PC200LC-7L ОСНОВН. НАСОС (ПЕРЕДН. БЛОК ЦИЛИНДРОВ) ГИДРАВЛИКА

|$0

708-2L-00300

PUMP ASS'Y,(SEE FIG. H0210-01A0)

|$1

708-2L-01301

PUMP SUB ASS'Y,(SEE FIG. H0210-01A0)

1

708-2L-32110

SHAFT,FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|$5

WASHER¤ 3.1MM

|$6

WASHER¤ 3.0MM

|$7

WASHER¤ 2.9MM

|$8

WASHER¤ 2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-2L-22160

SPACER

7

04065-06825

RING,SNAP

|$13

708-2L-06170

BLOCK ASS'Y,FRONT

8

BLOCK,CYLINDER

9

PLATE,VALVE

10

720-68-19610

PIN

11

04065-04818

RING,SNAP

12

708-2L-23131

SEAT

13

708-2L-33160

SPRING

14

708-7L-13140

SEAT

15

708-2L-23351

GUIDE,RETAINER

16

708-2L-23360

PIN

17

708-2L-33350

RETAINER,SHOE

18

708-2L-33310

PISTON SUB ASS'Y

|$25

708-2L-06190

CRADLE ASS'Y

19

CRADLE

20

CAM,ROCKER

21

04020-01228

PIN

22

01252-61230

BOLT
