Запчасти Komatsu PC200LC-7L МОТОР ПОВОРОТА (ВЕДУЩ. ВАЛ И БЛОК ЦИЛИНДРОВ) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$0

706-7G-03040

MOTOR SUB ASS'Y,(SEE FIG.N1220-02A0)

|$1

706-7G-03040

MOTOR SUB ASS'Y,(SEE FIG.N1220-02A0)

1

706-7G-41610

SHAFT,DRIVE

2

706-75-42880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

|$9

SPACER¤ 3.1MM

|$10

SPACER¤ 3.4MM

|$11

SPACER¤ 3.7MM

8

04064-04518

RING,SNAP

9

706-7E-11280

SEAL,OIL

10

706-75-43720

SPACER

11

04065-06220

RING

12

706-7G-41210

BLOCK,CYLINDER

13

706-7G-41710

PLATE,VALVE

14

706-75-43750

PIN,DOWEL

15

706-7G-41120

SHAFT,CENTER

16

706-7G-41130

RING,CENTER

17

706-7G-41140

SPRING

|$22

706-7G-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7G-41160

PISTON SUB ASS'Y

21

706-7G-91340

PLATE

22

706-7G-91350

DISC

23

706-7G-91110

PISTON,BRAKE

24

706-77-40370

O-RING

25

708-8F-31610

O-RING

26

706-7G-91360

SPRING
