Запчасти Komatsu PC200LC-7L МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-03040

MOTOR SUB ASS'Y,(SEE FIG.N1220-02A0)

2

22U-26-21280

RING

3

07042-00312

PLUG

4

20Y-26-31110

CASE

|$4

22U-26-21190

CASE

5

20Y-26-22330

BEARING

6

22U-26-22340

BEARING

|$7

22U-26-21340

BEARING

7

206-26-69111

SHAFT

|$9

206-26-69120

SHAFT¤ 13 TEETH

8

20Y-26-22420

SEAL

|$11

07012-00115

SEAL

9

20Y-26-22191

COVER

|$13

22U-26-21270

SPACER

10

01010-81045

BOLT

11

01643-31032

WASHER

12

07000-15310

O-RING

13

22U-26-21580

CARRIER

14

22U-26-21540

GEAR

15

20G-26-11240

BEARING

16

20Y-27-21240

WASHER

17

20Y-26-22250

PIN

18

20Y-27-21280

PIN

19

20Y-26-21240

PLATE

20

112-32-11211

BOLT¤ SHOE

21

22U-26-21551

GEAR

|$26

22U-26-21550

GEAR

22

20K-22-11190

O-RING

23

01010-81440

BOLT

24

01643-31445

WASHER

25

22U-26-21530

GEAR

26

22U-26-21570

CARRIER

27

22U-26-21520

GEAR

28

20Y-26-21281

BEARING

29

22U-26-21230

WASHER

30

22U-26-21210

PIN

31

04064-03515

RING

32

22U-26-21250

WASHER

33

22U-26-21510

GEAR

34

195-03-13241

VALVE

35

07270-21560

TUBE

36

07281-00197

CLAMP

37

01010-81035

BOLT

38

01643-51032

WASHER

39

20Y-26-31411

TUBE

|$45

20Y-26-31410

TUBE

40

20Y-26-31421

FILLER

|$47

20Y-26-31420

FILLER

41

20Y-26-31431

GAUGE

|$49

20Y-26-31430

GAUGE

42

20Y-26-31441

BRACKET

43

22U-26-21460

CAP

44

07238-10630

CONNECTOR

45

07283-32738

CLIP

46

04434-51710

CLIP

47

01597-01009

NUT

48

01643-31032

WASHER

49

01010-81030

BOLT

50

01643-31032

WASHER

51

01010-81025

BOLT

52

01643-31032

WASHER

53

07000-15240

O-RING

54

01010-82060

BOLT

55

01643-32060

WASHER
