Запчасти Komatsu PC200LC-7 БЛОК В СБОРЕ (ОХЛАЖД-Е) (ДЛЯ ОТОПИТЕЛЯ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

ND113140-0270

UNIT ASS'Y,HEATER

1

ND245450-2990

CASE,COOLING

2

ND245450-2980

CASE,COOLING

3

ND116120-7990

CORE ASS'Y,HEATER

4

ND116650-8800

DOOR ASS'Y

5

ND116650-8820

DOOR ASS'Y

6

ND116650-8840

DOOR ASS'Y

7

ND116640-4652

DAMPER ASS'Y

8

ND017231-1400

CLAMP

9

ND017660-3490

BRACKET

10

ND170400-4310

SENSOR ASS'Y,THERMO

11

ND146690-6020

CLAMP

12

ND246634-6010

BRACKET

13

ND499300-2051

I.C. POWER

14

ND063700-7200

SERVO MOTOR ASS'Y

15

ND063700-7210

SERVO MOTOR ASS'Y

16

ND116569-5020

PLATE

17

ND116682-0930

LEVER

18

ND116682-0960

LEVER

19

ND116662-4850

SHAFT

20

ND116569-5030

PLATE

21

ND116682-0940

LEVER

22

ND116682-0951

LEVER

23

ND116569-5041

PLATE

24

ND116569-5051

PLATE

25

ND116662-4860

SHAFT

26

ND116569-5062

PLATE

27

ND116682-0920

LEVER

28

ND116682-0910

LEVER

29

ND949008-0460

SCREW,TAPPING

30

17M-911-3290

CLAMP

31

ND146535-1311

BRACKET

32

ND146535-0411

BRACKET

33

ND146525-6070

BRACKET

34

ND91310-03081

SCREW,WASHER

35

ND949001-1730

SCREW,TAPPING

36

ND90930-05121

SCREW,TAPPING

37

ND90930-06141

SCREW,TAPPING

38

ND146535-0421

BRACKET

39

ND90930-05161

SCREW,TAPPING

40

ND116682-3440

LEVER

41

ND017730-8380

LEVER,CONTROL

42

ND116660-2770

DOOR ASS'Y

43

ND146698-6930

PACKING

44

ND146698-6950

PACKING

45

ND146698-8480

PACKING

46

ND146647-0712

PACKING

47

ND146625-7620

BUSHING
