Запчасти Komatsu PC200LC-7 ПРЕДПУСК. ПОДОГРЕВ (ОБОГРЕВАТЕЛЬ. В СБОРЕ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

20Y-977-1290

PRE HEATER ASS'Y

|$1

MKMX60APT-1

PRE HEATER ASS'Y

1

MK533 555

EXCHANGER ASS'Y,HEAT

2

MK533 576D

PIPE ASS'Y

3

MK533 586B

CHAMBER ASS'Y

4

MK533 588D

BOSS ASS'Y,GLOW PLUG

5

MK533 593

PIPE ASS'Y

6

MK059 143C

SENSOR ASS'Y

7

MK061 113A

GLOW PLUG ASS'Y

8

MK054 354

MOTOR ASS'Y

9

MK533 554

HOUSING

10

MK035 001

BLOWER

11

MK533 575A

SUPPORT

12

MK533 596A

AIR INLET

13

MK010 068A

O-RING

14

MK021 021

SPRING PIN

15

MK059 141

THERMOSTAT

16

MK059 142

THERMOSTAT

17

MK042 124A

THERMOSTAT

18

MK042 008

THERMOSTAT

19

MK007 287

BAND

20

MK011 098A

SHEET

21

MK011 099

PACKING

22

MK011 100

PACKING

23

MK011 101

PACKING

24

MK011 102

PACKING

25

MK007 016

CLAMP

26

MK003 081

WASHER

27

MK003 083

SHIM

28

MK003 084

SHIM

29

MK003 085

SHIM

30

MK016 184

HOSE

31

MKN102 221-210

JET

32

MK533 669

WICK,A

33

MK533 668

WICK,B

34

MK002 112

NUT,PLUG

35

MKSP-1/8

PLUG

36

MK001 041

RELEASE VALVE

37

MK010 014

O-RING

38

MK003 023

PACKING

39

MK007 124

CLIP,SPRING

40

MK007 035

CLAMP

41

MK015 005

CAP

42

MK533 399

PLATE

43

MK060 152

RESISTANCE ASS'Y

44

MK063 704A

CABLE

45

MK001 115A

SCREW

46

MK018 083

GROMMET

47

MK533 621

COVER ASS'Y

48

MK533 617

BRACKET ASS'Y

49

MKCW2=0306

SCREW

50

MKCW2=0408

SCREW

51

MKCW2=0510

SCREW

52

MKBW3=0516

BOLT

53

MK002 115

NUT

54

MKN1-06

NUT

55

MKBW3=0635

BOLT

56

MK001 130

SCREW

57

MK011 103

PACKING
