Запчасти Komatsu PC200LC-7 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.) (МОРОЗОУСТОЙЧИВ. СПЕЦИФ-Я)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR360

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0J360

CYLINDER ASS'Y

1

707-13-11561

CYLINDER

2

707-76-70110

BUSHING

3

07145-10070

SEAL,DUST (KIT)

4

707-58-80890

ROD,PISTON

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-11870

HEAD,CYLINDER

8

707-56-80820

SEAL,DUST (KIT)

9

707-88-04970

COLLAR

10

707-88-36881

RING

11

707-88-04980

PLATE

12

707-56-80740

SEAL,DUST (KIT)

13

707-52-90561

BUSHING

14

707-75-80040

RING,SNAP

15

707-51-80730

PACKING,ROD (KIT)

16

07000-55105

O-RING (KIT)

17

707-35-91150

RING,BACK-UP (KIT)

18

707-51-80640

RING,BUFFER (KIT)

19

01010-81695

BOLT

20

01011-81600

BOLT

21

01643-51645

WASHER

22

707-36-11851

PISTON

23

707-44-11280

RING,PISTON (KIT)

24

707-39-11530

RING,WEAR (KIT)

25

707-44-11920

RING

26

707-35-90360

RING,BACK-UP (KIT)

27

07000-55070

O-RING (KIT)

28

01310-01216

SCREW

29

07020-00000

FITTING,GREASE

30

07020-00000

FITTING,GREASE

31

707-11-31980

PLATE

32

707-86-66281

TUBE

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07372-21045

BOLT

36

01643-51032

WASHER

37

07000-53030

O-RING (KIT)

38

707-88-22570

BRACKET

39

707-88-21271

BAND

40

07372-21035

BOLT

41

01643-51032

WASHER

42

07283-32738

CLIP

43

01597-01009

NUT

44

01643-31032

WASHER

45

707-88-33030

CAP

46

07371-30640

FLANGE,SPLIT

47

07372-21035

BOLT

48

01643-51032

WASHER

KIT

707-99-38431

SERVICE KIT
