Запчасти Komatsu PC200LC-7 ГИДР. БАК. (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ И ПОВОРОТН. РУКОЯТЬ)(№9-) ГИДРАВЛИКА

1

20Y-60-31112

TANK

1

20Y-60-31111

TANK

1

20Y-60-31112

TANK

1

20Y-60-31111

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

02781-00628

UNION

7

02896-11018

O-RING

8

07002-12434

O-RING

9

02782-10522

ELBOW

10

02896-11015

O-RING

11

07002-12434

O-RING

12

02782-10315

ELBOW

13

02896-11009

O-RING

14

07002-12034

O-RING

15

11Y-62-12160

ELBOW

16

02896-11008

O-RING

17

07002-11423

O-RING

18

20Y-62-15660

ADAPTER

19

02782-10315

ELBOW

20

02783-10315

ELBOW

21

02896-11009

O-RING

22

07002-12034

O-RING

23

207-60-71182

ELEMENT

23

207-60-71181

ELEMENT

23

207-60-71182

ELEMENT

23

207-60-71181

ELEMENT

23

20Y-60-31121

ELEMENT

24

20Y-60-31140

STRAINER

25

20Y-60-31131

VALVE ASS'Y

26

20Y-60-21240

SPRING

27

22U-60-21231

COVER

28

07000-15195

O-RING

29

01010-81230

BOLT

30

01643-31232

WASHER

|$61

20Y-60-31171

STRAINER ASS'Y

31

207-60-61150

ROD ASS'Y

32

20Y-60-21320

HOLDER

33

12R-60-11230

SPRING

34

22B-60-11160

STRAINER

35

20Y-60-31161

COVER

36

07000-15160

O-RING

37

01010-81230

BOLT

38

01643-31232

WASHER

38

01643-31232

WASHER

39

17A-60-11310

CAP ASS'Y

40

20Y-60-21470

ELEMENT

41

208-60-71180

FILLER NECK

41

20Y-60-21460

NECK

41

208-60-71180

FILLER NECK

41

20Y-60-21460

NECK

42

20Y-60-21340

GASKET

43

01252-70516

BOLT

44

01601-20513

WASHER

45

07285-00155

CLIP

46

07270-61411

TUBE

47

205-00-73360

PLATE, OIL LEVEL

48

01010-81635

BOLT

49

01643-31645

WASHER
