Запчасти Komatsu PC200LC-7 ЦИЛИНДР РУКОЯТИ(СИСТЕМА СМАЗКИ 100 ЧАС.) (МОРОЗОУСТОЙЧИВ. СПЕЦИФ-Я)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR350

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0J350

CYLINDER ASS'Y

1

707-13-13540

CYLINDER

2

707-76-80010

BUSHING

3

07145-10080

SEAL,DUST (KIT)

4

707-58-95290

ROD,PISTON

5

707-27-13970

HEAD,CYLINDER

6

707-56-95820

SEAL,DUST (KIT)

7

707-88-04950

COLLAR

8

707-88-04960

PLATE

9

707-88-04940

RING

10

707-56-95740

SEAL,DUST (KIT)

11

707-52-90721

BUSHING

12

707-75-95030

RING,SNAP

13

707-51-95730

PACKING,ROD (KIT)

14

07000-55125

O-RING (KIT)

15

707-35-91370

RING,BACK-UP (KIT)

16

707-51-95640

RING,BUFFER (KIT)

17

01011-81800

BOLT

18

01011-81805

BOLT

19

707-41-11840

WASHER

20

707-36-13771

PISTON

21

707-44-13280

RING,PISTON (KIT)

22

707-39-13530

RING,WEAR (KIT)

23

707-44-13920

RING

24

707-71-61070

PLUNGER

25

07000-55085

O-RING (KIT)

26

707-35-90960

RING,BACK-UP (KIT)

27

01310-01216

SCREW

28

707-71-70270

PLUNGER

29

07020-00000

FITTING,GREASE

30

707-71-32770

COLLAR

31

707-35-91370

RING,BACK-UP (KIT)

32

07000-55125

O-RING (KIT)

33

04260-00635

BALL

34

707-71-91270

CAP

35

707-83-13010

VALVE

36

07750-01628

SPRING

37

707-87-14070

PLUG

38

07002-52034

O-RING (KIT)

39

700-11-31980

PLATE, NAME

40

707-86-66270

TUBE

41

20D-62-17860

ELBOW

42

07372-21060

BOLT

43

01643-51032

WASHER

44

07372-21045

BOLT

45

01643-51032

WASHER

46

07000-53030

O-RING (KIT)

47

01010-81080

BOLT

48

01643-51032

WASHER

49

07000-53035

O-RING (KIT)

50

707-88-22530

BRACKET

51

707-88-21261

BAND

52

07372-21035

BOLT

53

01643-51032

WASHER

54

707-88-11560

PLATE

55

07283-32738

CLIP

56

01597-01009

NUT

57

01643-31032

WASHER

58

707-88-33040

CAP

59

07371-31049

FLANGE,SPLIT

60

707-88-33030

CAP

61

07371-30640

FLANGE,SPLIT

62

07372-21035

BOLT

63

01643-51032

WASHER

|$71

707-99-50691

SERVICE KIT
