Запчасти Komatsu PC200LC-7 РУКОЯТЬ (.8M) ( ЧАС. СИСТЕМА СМАЗКИ) (С ДОПОЛН. ГИДРОЛИНИЕЙ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$8

20Y-70-00742

ARM ASS'Y

|$9

20Y-70-00741

ARM ASS'Y

|$10

20Y-70-00740

ARM ASS'Y

1

ARM

1

ARM

2

20Y-970-3560

BRACKET (WELDED)

3

20Y-970-3570

BRACKET (WELDED)

4

20Y-70-31272

BUSHING

4

20Y-70-31271

BUSHING

5

20Y-70-32410

BUSHING

5

20Y-70-32321

BUSHING

6

20Y-70-32331

BUSHING

7

205-70-73180

BUSHING

7

20Y-70-32371

BUSHING

8

07020-00000

FITTING

9

07145-00090

SEAL

10

20Y-70-23220

SEAL

11

20Y-70-23230

SEAL

12

20Y-70-11182

PIN

12

20Y-70-11180

PIN

13

205-70-66581

PLATE

13

205-70-66580

PLATE

14

01010-81230

BOLT

15

01643-31232

WASHER

16

21K-70-71650

SPACER, 1.0MM

16

20Y-70-31431

SPACER, 1.0MM

16

20Y-70-31430

SPACER, 1.0MM

17

205-70-71191

PIN

17

205-70-71190

PIN

18

205-70-66580

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

21K-70-71630

SPACER, 1.0MM

21

20Y-70-31381

SPACER, 1.0MM

21

20Y-70-31380

SPACER, 1.0MM

22

21K-70-71640

SPACER, 2.0MM

22

20Y-70-31391

SPACER, 2.0MM

22

20Y-70-31390

SPACER, 2.0MM

23

707-01-XT641

CYLINDER GROUP

23

707-01-XX200

CYLINDER GROUP
