Запчасти Komatsu PC200LC-7 2-СЕКЦИОНН. СТРЕЛА (ВТОР. СТРЕЛА И СОЕДИНЕНИЕ ПАЛЕЦ)(№9-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

20Y-966-3312

BOOM

1

20Y-966-3311

BOOM

1

20Y-966-3312

BOOM

1

20Y-966-3311

BOOM

1

20Y-966-3310

BOOM

2

205-966-5340

SEAT (WELDED)

3

20Y-62-13760

SEAT (WELDED)

4

20Y-62-34120

BRACKET (WELDED)

5

20Y-62-45740

BRACKET (WELDED)

6

20Y-62-45760

BRACKET (WELDED)

7

20Y-70-31252

PIN

7

20Y-70-31251

PIN

7

20Y-70-31250

PIN

8

22U-70-31340

SPACER, 2.5MM

8

20Y-70-31521

SPACER, 2.5MM

8

20Y-70-31520

SPACER, 2.5MM

8

20Y-70-31521

SPACER, 2.5MM

8

20Y-70-31520

SPACER, 2.5MM

8

22U-70-31350

SPACER, 3.0MM

8

20Y-70-31531

SPACER, 3.0MM

8

20Y-70-31530

SPACER, 3.0MM

8

20Y-70-31531

SPACER, 3.0MM

8

20Y-70-31530

SPACER, 3.0MM

8

22U-70-31280

SPACER, 2.0MM

8

20Y-70-31372

SPACER, 2.0MM

8

20Y-70-31371

SPACER, 2.0MM

8

20Y-70-31372

SPACER, 2.0MM

8

20Y-70-31371

SPACER, 2.0MM

9

205-70-71312

PLATE

9

205-70-71310

PLATE

10

01010-81235

BOLT

11

01643-31232

WASHER

12

20Y-70-11182

PIN

12

20Y-70-11180

PIN

12

20Y-70-11182

PIN

12

20Y-70-11180

PIN

13

20Y-70-31431

SPACER, 1.0MM

13

20Y-70-31430

SPACER, 1.0MM

13

20Y-70-31431

SPACER, 1.0MM

13

20Y-70-31430

SPACER, 1.0MM

13

206-70-71451

SPACER, 2.0MM

13

206-70-71450

SPACER, 2.0MM

13

206-70-71451

SPACER, 2.0MM

13

206-70-71450

SPACER, 2.0MM

14

205-70-66581

PLATE

14

205-70-66580

PLATE

14

205-70-66581

PLATE

14

205-70-66580

PLATE

15

01010-81230

BOLT

16

01643-31232

WASHER

17

208-70-61191

PIN

18

207-70-72391

SPACER, 2.0MM

18

207-70-72390

SPACER, 2.0MM

18

207-70-72391

SPACER, 2.0MM

18

207-70-72390

SPACER, 2.0MM

19

205-70-66580

PLATE

20

01010-81235

BOLT

21

01643-31232

WASHER

22

07020-00000

FITTING
