Запчасти Komatsu PC200LC-7 2-СЕКЦИОНН. СТРЕЛА (ПЕРВ. СТРЕЛА И ADJUST ПАЛЕЦ ЦИЛИНДРА)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

20Y-966-3112

BOOM

1

20Y-966-3111

BOOM

1

20Y-966-3112

BOOM

1

20Y-966-3111

BOOM

2

20Y-62-24170

BRACKET (WELDED)

3

20Y-62-45182

BRACKET (WELDED)

4

20Y-62-45210

BRACKET (WELDED)

5

20Y-62-45740

BRACKET (WELDED)

6

20Y-62-45750

BRACKET (WELDED)

7

20Y-62-46230

BRACKET (WELDED)

8

20Y-70-11651

SEAT (WELDED)

9

20Y-70-31512

BUSHING

9

20Y-70-31511

BUSHING

9

20Y-70-31512

BUSHING

9

20Y-70-31511

BUSHING

10

07145-00090

SEAL

11

07049-01215

PLUG

12

208-70-72541

BUSHING

12

20Y-70-31710

BUSHING

12

208-70-72541

BUSHING

12

20Y-70-31710

BUSHING

13

208-70-61191

PIN

14

207-70-72391

SPACER, 2.0MM

14

207-70-72390

SPACER, 2.0MM

14

207-70-72391

SPACER, 2.0MM

14

207-70-72390

SPACER, 2.0MM

14

207-70-72421

SPACER, 2.5MM

14

207-70-72420

SPACER, 2.5MM

14

207-70-72421

SPACER, 2.5MM

14

207-70-72420

SPACER, 2.5MM

14

207-70-72431

SPACER, 3.0MM

14

207-70-72430

SPACER, 3.0MM

14

207-70-72431

SPACER, 3.0MM

14

207-70-72430

SPACER, 3.0MM

15

205-70-66580

PLATE

16

01010-81235

BOLT

17

01643-31232

WASHER

18

07020-00900

FITTING
