Запчасти Komatsu PC200LC-7 ЧАСТИ ОСНОВНОЙ РАМЫ(№-) ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

20Y-46-41203

FRAME

1

20Y-46-41202

FRAME

1

20Y-46-41201

FRAME

2

205-30-71181

COVER

3

205-30-71191

GASKET

4

01010-81230

BOLT

5

01643-31232

WASHER

6

20Y-46-41280

PLUG

7

20Y-54-61670

BRACKET

8

20Y-54-61680

BRACKET

9

01010-81230

BOLT

10

01643-31232

WASHER

|$28

20Y-46-42412

COVER

|$29

20Y-46-42411

COVER

11

COVER

11

COVER

12

20Y-46-42232

SEAL

12

20Y-46-42231

SEAL

13

20Y-46-42460

SHEET

|$37

20Y-46-42427

COVER

|$38

20Y-46-42423

COVER

|$39

20Y-46-42422

COVER

14

COVER

14

COVER

14

COVER

15

20Y-46-42253

SEAL

15

20Y-46-42252

SEAL

15

20Y-46-42251

SEAL

16

20Y-46-42460

SHEET

17

20Y-46-42470

SEAL

18

20Y-46-42480

SEAL

|$52

20Y-46-42433

COVER

|$53

20Y-46-42432

COVER

|$54

20Y-46-42431

COVER

19

COVER

19

COVER

19

COVER

20

20Y-46-42243

SEAL

20

20Y-46-42242

SEAL

20

20Y-46-42241

SEAL

21

20Y-46-42460

SHEET

22

20Y-46-42490

SEAL

|$66

20Y-46-42440

COVER

23

COVER

23

COVER

24

20Y-46-42260

SHEET
