Запчасти Komatsu PC200LC-7 PPC ОСНОВН. ТРУБЫ (БЛОК) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ И ПОВОРОТН. РУКОЯТЬ)(№9-) ГИДРАВЛИКА

1

20Y-62-43430

BLOCK

2

01010-80820

BOLT

3

01643-30823

WASHER

4

20Y-62-43450

PLATE

5

20Y-62-43440

BRACKET

6

01010-81225

BOLT

7

01643-31232

WASHER

8

20Y-62-22271

ELBOW

9

201-60-11390

O-RING

10

20Y-62-19560

O-RING

11

07002-11423

O-RING

12

14X-43-14840

ELBOW

13

201-60-11390

O-RING

14

20Y-62-19560

O-RING

15

07002-11423

O-RING

16

20Y-62-16630

NIPPLE

17

201-60-11390

O-RING

18

20Y-62-19560

O-RING

19

07002-11423

O-RING

20

206-06-61130

SWITCH

21

20Y-06-22430

WIRING HARNESS

22

08053-01512

CLIP

23

195-33-11220

SPACER

24

01010-81045

BOLT

25

01643-31032

WASHER

26

04434-53412

CLIP

27

01010-81225

BOLT

28

01643-31232

WASHER

29

20Y-62-43980

HOSE, 1450MM

30

20Y-62-22810

BAND, YELLOW

31

20Y-62-43990

HOSE, 2150MM

32

20Y-62-22840

BAND, BLACK

33

20Y-62-22860

BAND, BROWN

34

207-62-72720

HOSE, 1400MM

35

20Y-62-43520

HOSE, 2100MM

36

08034-20536

BAND

37

04434-53412

CLIP
