Запчасти Komatsu PC200LC-6Z ЦИЛИНДР КОВША (ДЛЯ 1.8M РУКОЯТИ)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

205-63-X9100

CYLINDER GROUP

G-1

205-63-X3140

BUCKET CYLINDER G.

|$5

205-63-03140

CYLINDER ASS'Y

1

205-63-71540

CYLINDER

2

707-76-70160

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

205-63-71520

ROD,PISTON

5

707-76-70160

BUSHING

6

21K-70-12180

SEAL,DUST (KIT)

7

707-27-12960

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15115

O-RING (KIT)

13

707-35-91250

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12670

PISTON

18

707-44-12280

RING,PISTON (KIT)

19

707-39-12530

RING,WEAR (KIT)

20

707-44-12921

RING

21

707-35-90930

RING,BACK-UP (KIT)

22

07000-15075

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

205-63-71570

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-87090

BRACKET

31

707-88-87150

BAND

32

01010-51035

BOLT

33

01643-51032

WASHER

34

707-88-13590

CLAMP

35

01010-51040

BOLT

36

01643-31032

WASHER
