Запчасти Komatsu PC200LC-6Z РАБОЧАЯ ЛИНИЯ PPC (ПАТРУБКИ ПРАВОЙ СТОЙКИ) ( АКТУАТОР)(№89-899) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-18461

HOSE

2

20Y-62-23281

HOSE

3

20Y-62-23280

HOSE

4

20Y-62-23930

HOSE

5

20Y-62-23960

HOSE

6

20Y-62-22170

CLAMP

7

20Y-62-22790

BAND, RED

8

20Y-62-22820

BAND, BLUE

9

20Y-62-22830

BAND, WHITE

10

20Y-62-22840

BAND, BLACK

11

20Y-62-22850

BAND, GREEN

12

20Y-62-22860

BAND, BROWN

13

702-16-53240

PLUG

14

07000-02018

O-RING

15

20Y-62-16170

BOLT

16

07000-02015

O-RING

17

20Y-62-22180

CLAMP

18

01010-51016

BOLT

19

01643-31032

WASHER

20

20Y-62-22920

HOSE, 2000MM

21

20Y-62-23920

HOSE, 2200MM

22

20Y-62-22190

CLAMP

23

20Y-62-22790

BAND, RED

24

20Y-62-22820

BAND, BLUE

25

20Y-62-22151

BLOCK

26

01010-51050

BOLT

27

01643-31032

WASHER

28

07235-10315

ELBOW

29

07002-02034

O-RING

30

207-62-33920

ELBOW

31

07002-01423

O-RING

32

205-62-55270

NIPPLE

33

07002-01423

O-RING

34

21T-62-29960

TEE

35

07002-01423

O-RING

36

20Y-62-22210

BRACKET

37

01010-51016

BOLT

38

01643-31032

WASHER

39

08036-01414

CLIP

40

01010-51230

BOLT

41

01643-31232

WASHER

42

08034-00519

BAND
