Запчасти Komatsu PC200LC-6Z КОНДИЦ. ВОЗДУХА (БЛОК)(№987-9) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

201-979-7111

AIR CONDITIONER UNIT

2

114-X11-3850

FILTER

3

203-979-6591

FILTER

4

01010-51020

BOLT

5

01643-31032

WASHER

6

201-979-7170

HOSE

7

201-979-7170

HOSE

8

08034-00519

BAND

9

201-979-7180

DUCT

10

01023-20510

SCREW

11

20Y-979-2250

SEAL

12

203-979-6380

CONDENSER ASS'Y

13

203-979-6610

RECEIVER DRYER

14

01010-51025

BOLT

15

01643-31032

WASHER

16

20Y-979-5310

BRACKET

17

01010-51025

BOLT

18

01643-31032

WASHER

19

07283-27060

CLIP

20

01599-01011

NUT

21

01643-31032

WASHER

22

203-979-6580

COMPRESSOR ASS'Y

23

20Y-979-5342

BRACKET

24

01010-51070

BOLT

25

01643-31032

WASHER

26

01010-51030

BOLT

27

01643-31032

WASHER

28

01010-51030

BOLT

29

01643-31032

WASHER

30

20Y-03-21620

BRACKET

31

01010-51025

BOLT

32

01643-31032

WASHER

33

208-62-38370

CLIP

34

01010-51020

BOLT

35

01643-31032

WASHER

36

20U-54-28280

COVER

37

01220-70820

SCREW

38

01643-80823

WASHER
