Запчасти Komatsu PC200LC-6Z КОНДИЦ. ВОЗДУХА (БЛОК)(№89-98) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

201-979-7111

AIR CONDITIONER UNIT

2

114-X11-3850

FILTER

3

203-979-6591

FILTER

4

01010-51020

BOLT

5

01643-31032

WASHER

6

201-979-7170

HOSE

7

201-979-7170

HOSE

7

209-979-1250

HOSE

7A

08034-00519

BAND

8

201-979-7180

DUCT

9

01023-20510

SCREW

10

20Y-979-2250

SEAL

11

203-979-6380

CONDENSER ASS'Y

12

203-979-6610

RECEIVER DRYER

13

01010-51025

BOLT

14

01643-31032

WASHER

15

20Y-979-5310

BRACKET

16

01010-51025

BOLT

17

01643-31032

WASHER

18

07283-27060

CLIP

19

01599-01011

NUT

20

01643-31032

WASHER

21

203-979-6580

COMPRESSOR ASS'Y

22

20Y-979-5342

BRACKET

22

20Y-979-5341

BRACKET

23

01010-51070

BOLT

24

01643-31032

WASHER

25

01010-51030

BOLT

26

01643-31032

WASHER

27

01010-51030

BOLT

28

01643-31032

WASHER

29

20Y-03-21620

BRACKET

30

01010-51025

BOLT

31

01643-31032

WASHER

32

208-62-38370

CLIP

33

01010-51020

BOLT

34

01643-31032

WASHER

35

20Y-979-5190

COVER

36

01010-51025

BOLT

37

01643-31232

WASHER
