Запчасти Komatsu PC200LC-6Z ГИДР. БАК. (БЕЗ ДАТЧИКА)(№9999-9) ГИДРАВЛИКА

|$2

20Y-60-00061

HYDRAULIC TANK ASS'Y

1

TANK

2

208-04-19130

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

20Y-966-2970

TEE

7

07002-02434

O-RING

8

07236-10628

ELBOW

9

07002-02434

O-RING

9A

209-62-57210

TEE

9B

07002-02034

O-RING

10

20Y-60-21211

CASE

11

07063-01210

ELEMENT

12

206-60-41221

STRAINER

13

12R-60-11300

VALVE ASS'Y

14

20Y-60-21240

SPRING

15

COVER

16

07000-05165

O-RING

17

01010-51240

BOLT

18

01643-31232

WASHER

19

HEAD

20

07000-05210

O-RING

21

20Y-60-21230

RING

22

20Y-60-21260

PACKING

23

01010-51240

BOLT

24

01643-31232

WASHER

25

20Y-60-11650

PLUG

26

7861-91-4220

O-RING

27

01010-50612

BOLT

28

01641-20608

WASHER

|$37

20Y-60-21301

STRAINER ASS'Y

29

20Y-60-21330

ROD ASS'Y

30

20Y-60-21320

HOLDER

31

12R-60-11230

SPRING

32

01580-11008

NUT

33

20Y-60-21311

STRAINER

34

COVER

35

07000-05180

O-RING

36

01010-51225

BOLT

37

01643-31232

WASHER

38

20Y-60-21440

CAP

38

20Y-60-21470

ELEMENT

39

20Y-60-21460

NECK,FILLER

40

205-60-66211

GASKET

41

01220-40516

SCREW

42

01601-20513

WASHER

43

07285-00155

CLIP

44

207-26-31220

TUBE

45

07221-20315

NUT

46

07222-00312

PLUG

47

01010-51635

BOLT

48

01643-31645

WASHER
