Запчасти Komatsu PC200LC-6LE FIG. H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН - BASIC СЕКЦ. ГИДРАВЛИКА

1

723-46-13502

MAIN CONTROL VALVE ASSEMBLY

2

207-62-22271

ELBOW

3

201-60-11390

O-RING

4

20Y-62-19560

O-RING

5

07235-10210

ELBOW

6

208-26-11611

TEE

7

07002-11423

O-RING

8

208-62-17550

TEE

9

07002-11423

O-RING

10

20Y-62-27680

ADAPTER

11

07002-11423

O-RING

12

07235-10210

ELBOW

13

07002-11423

O-RING

14

20Y-62-23541

ELBOW

15

07002-11423

O-RING

|$15

20Y-60-22261

VALVE ASSEMBLY, LS LINE

16

20Y-60-22210

BODY

17

20Y-60-22270

POPPET

18

701-20-61230

SPRING

19

07230-20210

UNION

20

07002-11423

O-RING

21

07002-11423

O-RING

22

205-62-74190

ELBOW

23

07002-11223

O-RING

24

208-62-17550

TEE

25

07002-11423

O-RING

26

208-62-17550

TEE

27

07002-11423

O-RING

28

208-62-17550

TEE

29

07002-11423

O-RING

30

20Y-62-22160

ADAPTER

31

07002-11423

O-RING

32

208-26-11611

TEE

33

07002-11423

O-RING

34

07096-00204

HOSE

35

07235-10210

ELBOW

36

07002-11423

O-RING

37

207-62-61680

TEE

38

799-10-15230

NIPPLE, LS PRESSURE TEST PORT

39

209-62-61330

O-RING

40

07002-11423

O-RING
