Запчасти Komatsu PC200LC-6LE FIG. A9-AA ГЕНЕРАТОР - SI V/ AMP ДВИГАТЕЛЬ
№
Артикул
Название
Примечание
Количество
|$0
6742-01-5170
ALTERNATOR (PRODUCTION ONLY)
|$1
1316 279 H91
ALTERNATOR (SERVICE ONLY)
1
1218 115 H1
REGULATOR-GENERATOR
2
1315 828 H1
COVER
3
1218 126 H1
NUT
4
1316 280 H1
ROTOR-GENERATOR
5
1307 332 H1
CONNECTOR
6
1310 140 H1
STATOR ASSEMBLY
7
1316 281 H1
SRE FRAME
8
389 603 C91
ROLLER BEARING
9
1213 242 H1
BUSHING
10
1307 329 H1
DIODE TRIO
11
1307 334 H1
CAPACITOR
12
1315 820 H1
RECTIFIER BRIDGE
13
1316 282 H1
NUT
14
1268 365 H1
SCREW & WASHER
15
1316 283 H1
BRUSH HOLDER & BRUSH ASSEMBLY
16
1316 284 H1
WASHER
17
1236 654 H1
SCREW
18
1216 375 H1
SCREW
19
1268 365 H1
SCREW
20
1307 339 H1
SCREW
21
1316 287 H1
FRAME - DE
22
1213 268 H1
BALL BEARING - DE
23
1307 337 H1
PLATE
24
1268 363 H1
SCREW
25
VE8211
NUT
26
1316 288 H1
BOLT, THRU
27
1307 576 H1
FAN & BAFFLE
28
1307 578 H1
SCREW
29
1307 330 H1
TERMINAL PACKAGE - BATTERY
30
1316 285 H1
TERMINAL PACKAGE - RELAY
31
1316 286 H1
TERMINAL PACKAGE - INDICATOR LIGHT
|$0
6742-01-5170
ALTERNATOR (PRODUCTION ONLY)
|$1
1316 279 H91
ALTERNATOR (SERVICE ONLY)
1
1218 115 H1
REGULATOR-GENERATOR
2
1315 828 H1
COVER
3
1218 126 H1
NUT
4
1316 280 H1
ROTOR-GENERATOR
5
1307 332 H1
CONNECTOR
6
1310 140 H1
STATOR ASSEMBLY
7
1316 281 H1
SRE FRAME
8
389 603 C91
ROLLER BEARING
9
1213 242 H1
BUSHING
10
1307 329 H1
DIODE TRIO
11
1307 334 H1
CAPACITOR
12
1315 820 H1
RECTIFIER BRIDGE
13
1316 282 H1
NUT
14
1268 365 H1
SCREW & WASHER
15
1316 283 H1
BRUSH HOLDER & BRUSH ASSEMBLY
16
1316 284 H1
WASHER
17
1236 654 H1
SCREW
18
1216 375 H1
SCREW
19
1268 365 H1
SCREW
20
1307 339 H1
SCREW
21
1316 287 H1
FRAME - DE
22
1213 268 H1
BALL BEARING - DE
23
1307 337 H1
PLATE
24
1268 363 H1
SCREW
25
VE8211
NUT
26
1316 288 H1
BOLT, THRU
27
1307 576 H1
FAN & BAFFLE
28
1307 578 H1
SCREW
29
1307 330 H1
TERMINAL PACKAGE - BATTERY
30
1316 285 H1
TERMINAL PACKAGE - RELAY
31
1316 286 H1
TERMINAL PACKAGE - INDICATOR LIGHT
Выбрано товаров: 66
