Запчасти Komatsu PC200LC-6LE FIG. A9-AA ГЕНЕРАТОР - SI V/ AMP ДВИГАТЕЛЬ

Схема запчастей Komatsu PC200LC-6LE - FIG. A9-AA ГЕНЕРАТОР - SI V/ AMP ДВИГАТЕЛЬ
34
32
9
28
15
23
19
16
27
29
4
10
11
18
2
7
1
26
24
8
6
17
5
21
3
33
22
25
31
30
13
14
12

Артикул

Название

Примечание

Количество

|$0

1307 203 H1

ALTERNATOR (PRODUCTION ONLY)

|$1

1310 137 H91

ALTERNATOR (SERVICE ONLY)

1

1307 324 H1

FRAME SRE

2

1236 651 H1

BEARING SRE

3

1307 325 H1

ROTOR ASSEMBLY

4

1310 140 H1

STATOR ASSEMBLY

5

1307 327 H1

FRAME DE

6

1213 268 H1

BEARING DE

7

1310 141 H1

RECTIFIER BRIDGE ASSEMBLY

8

1307 329 H1

DIODE TRIO

9

1218 115 H1

REGULATOR

10

1307 330 H1

TERMINAL PKG - OUTPUT

11

1307 331 H1

TERMINAL PKG - RELAY

12

1307 332 H1

CONNECTOR REGULATOR STUD

13

1307 333 H1

CONNECTOR RELAY TERMINAL

14

1307 334 H1

CAPACITOR

15

1307 335 H1

BRUSH HOLDER ASSEMBLY

16

1307 336 H1

BRUSH & ARM

17

1307 337 H1

RETAINER PLATE - DE

18

1218 242 H1

BUSHING HINGE - SRE

19

1218 130 H1

COVER - REGULATOR TERMINAL

N/I

1213 274 H1

CAP - RELAY TERMINAL

21

1307 338 H1

FAN

22

1310 142 H1

PULLEY

23

1218 126 H1

NUT -REGULATOR

24

120 622

NUT - RECTIFIER BRIDGE

25

1213 273 H1

NUT - SHAFT

26

1268 365 H1

SCREW (& LOCK WASHER) RECT. BRIDGE ATCH

27

1236 654 H1

SCREW - BRUSH HOLDER ATCH (PIVOT)

28

1268 365 H1

SCREW - REGULATOR ATCH (GROUND)

29

1216 375 H1

SCREW - REGULATOR ATCH (INSUL)

30

1307 339 H1

SCREW - CAPACITOR ATCH

31

1268 363 H1

SCREW - BRG RETAINER PLATE ATCH

32

1307 340 H1

SCREW - (& LOCK WASHER) - GROUND - SRE FRAME

33

1268 370 H1

WASHER - SHAFT NUT

34

1307 341 H1

BOLT - THRU

Выбрано товаров: 36
