Запчасти Komatsu PC200LC-6LE FIG. T-A ЦИЛИНДР КОВША - .9 M (9 FT IN) РУКОЯТЬ РАЗРУШ. ЗДАНИЙ СПЕЦ-Я РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

206-63-03130

CYLINDER ASSEMBLY, BUCKET

1

206-63-74740

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST

4

206-63-74720

ROD, PISTON

5

707-76-80020

BUSHING

6

205-70-62140

SEAL, DUST

7

707-27-13921

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL

10

707-52-90680

BUSHING

11

707-51-90030

PACKING, ROD

12

07000-15120

O-RING

13

707-35-91320

RING, BACK-UP

14

707-51-90630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13471

PISTON

18

707-44-13180

RING, PISTON

19

707-39-13110

RING, WEAR

20

707-44-13911

RING

21

707-35-90940

RING, BACK-UP

22

07000-15080

O-RING

23

01310-01216

SCREW

24

07020-00000

FITTING, GREASE

25

07020-00900

FITTING, GREASE

26

206-63-74770

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING

30

707-88-95980

BRACKET

31

707-88-96100

BAND

32

01010-81035

BOLT

33

01643-81032

WASHER

34

07282-02793

CLAMP

35

01010-81020

BOLT

36

01643-31032

WASHER

|$37

707-99-47670

SERVICE KIT, BUCKET CYLINDER
