Запчасти Komatsu PC200LC-6LE FIG. T-9A ЦИЛИНДР КОВША - .8 M ( FT IN) РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

205-63-03140

CYLINDER ASSEMBLY

1

205-63-71540

CYLINDER

2

707-76-70160

BUSHING

3

07145-00070

SEAL, DUST

4

205-63-71520

ROD, PISTON

5

707-76-70160

BUSHING

6

21K-70-12180

SEAL, DUST

7

707-27-12960

HEAD, CYLINDER

8

07179-13099

RING, SNAP

9

707-56-85510

SEAL, DUST

10

707-52-90610

BUSHING

11

707-51-85030

PACKING, ROD

12

07000-15115

O-RING

13

707-35-91250

RING, BACK-UP

14

707-51-85630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12670

PISTON

18

707-44-12280

RING, PISTON

19

707-39-12530

RING, WEAR

20

707-44-12921

RING

21

707-35-90930

RING, BACK-UP

22

07000-15075

O-RING

23

01310-01216

SCREW

24

07020-00000

FITTING, GREASE

25

07020-00900

FITTING, GREASE

26

205-63-71570

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING

30

707-88-87090

BRACKET

31

707-88-87150

BAND

32

01010-51035

BOLT

33

01643-51032

WASHER

34

707-88-13590

CLAMP

35

01010-51040

BOLT

36

01643-31032

WASHER

|$37

707-99-46290

SERVICE KIT, BUCKET CYLINDER
