Запчасти Komatsu PC200LC-6LE FIG. P-A МОТОР ХОДА НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8F-00111

TRAVEL MOTOR

1

708-8F-04640

CASE

2

NSS

PLUG

|$3

708-8F-04623

END COVER

3

NSS

COVER, END

4

NSS

SPOOL

5

NSS

PLUG

6

NSS

PLUG

7

708-8H-11530

PLUG

8

07002-11423

O-RING

9

20B-27-11210

BLEEDER

10

708-8F-36611

SPRING

11

NSS

RING

12

708-8H-36121

SPRING

13

708-8F-36311

COVER

14

07000-13040

O-RING

15

700-93-11320

O-RING

16

07000-11009

O-RING

17

01252-61235

BOLT

18

708-8F-34160

SPOOL

19

708-8F-34170

SPRING

20

708-8H-34210

SEAT

21

708-8H-34180

RING

22

708-8F-34120

VALVE

23

722-10-91130

SPRING

24

708-8F-34110

PLUG

25

07002-11823

O-RING

26

708-8E-16180

VALVE

27

708-8E-16160

PLUG

28

07002-11023

O-RING

29

708-8F-31610

O-RING

30

07000-11009

O-RING

31

04020-01228

PIN

32

708-8F-31210

BOLT

|$34

702-73-02111

CROSS OVER RELIEF VALVE

33

NSS

SLEEVE

34

NSS

VALVE

35

NSS

SPRING

36

NSS

SEAL

37

NSS

SCREW

38

NSS

NUT

39

708-8F-32110

SHAFT

40

708-8F-12151

BEARING

41

708-7L-12140

BEARING

42

708-7L-05010

SPACER KIT

43

706-7G-11291

SEAL, OIL

44

708-8F-12230

SPACER, 3.2 MM

45

04065-07225

RING

46

708-8F-33110

BLOCK, CYLINDER

47

708-8F-33210

PLATE, VALVE

48

720-68-19610

PIN

49

708-8F-33360

PIN

50

708-7L-13140

SEAT

51

708-8F-33150

SPRING

52

04065-04818

RING, SNAP

53

708-8F-33350

GUIDE, RETAINER

54

708-8F-33340

SHOE, RETAINER

55

708-8F-33310

PISTON ASSEMBLY

56

708-8F-33411

CAM, ROCKER

57

708-8F-33710

BALL, RETAINER

58

708-8F-34141

PISTON

59

708-8F-34150

SPRING

60

708-8F-35110

PLATE

61

708-8F-35130

PLATE

62

708-8F-35120

DISC

63

708-8F-35140

PISTON, BRAKE

64

708-8F-35160

O-RING

65

708-8F-35170

RING, BACK-UP

66

708-8F-35180

O-RING

67

708-8F-35190

RING, BACK-UP

68

708-8F-35150

SPRING

69

04025-00324

PIN
