Запчасти Komatsu PC200LC-6H ГЛАВН. КЛАПАН(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|$4
702-21-09147
VALVE ASS'Y
|$5
702-21-09146
VALVE ASS'Y
|$6
702-21-09145
VALVE ASS'Y
|$7
702-21-09143
VALVE ASS'Y
1
BLOCK
2
VALVE
3
702-21-55460
SPRING
4
702-21-55420
O-RING
5
702-21-55520
O-RING
5
702-21-55430
O-RING
6
702-21-55440
O-RING
7
702-21-53120
FILTER
8
07000-11009
O-RING
9
702-21-55410
PLATE
10
01252-60820
BOLT
11
01643-50823
WASHER
12
702-21-55530
O-RING
12
702-21-55450
O-RING
13
BLOCK
14
SPOOL
15
SLEEVE
16
SPRING
17
SCREW
17
SCREW
18
SPRING
19
WASHER
20
POPPET
20
POPPET
21
702-21-55620
PLUG
22
07002-11423
O-RING
23
NUT
24
O-RING
25
O-RING
26
07002-11623
O-RING
27
702-21-55710
SEAT
28
702-21-55720
SPRING
29
04260-00793
BALL
30
07000-11009
O-RING
31
PLUG
31
PLUG
32
702-21-55670
ORIFICE
33
702-21-55470
ORIFICE
34
01252-60520
BOLT
35
702-21-55480
FRANGE
36
07000-12020
O-RING
37
01252-61025
BOLT
|$54
702-21-55100
VALVE ASS'Y,RELIEF
38
SLEEVE
39
COLLAR
40
FILTER
41
POPPET
42
SPRING
43
SCREW
44
NUT
45
O-RING
46
O-RING
47
O-RING
48
07002-11623
O-RING
Выбрано товаров: 58
