Артикул
Название
Примечание
Количество
1
20Y-06-23312
BASE
2
20Y-06-24120
SWITCH ASS'Y
2A
01641-21223
WASHER
3
569-06-61960
RELAY
4
01435-00610
BOLT
5
20Y-06-21270
WIRING HARNESS
6
283-06-16110
BOX
7
283-06-16120
COVER
8
20Y-06-24130
SWITCH
9
283-06-16190
FUSE, 10A
10
205-06-73180
FUSE, 15A
11
22W-06-13160
FUSE, 20A
12
08020-00000
DIODE
13
20Y-06-24270
CLIP
14
20Y-06-21460
CLIP
15
20Y-06-23960
CLIP
16
01023-10625
SCREW
17
20Y-979-2130
BOX ASS'Y,(SEE FIG. Y1979-61A0)
18
01435-01016
BOLT
19
20Y-979-2221
DUCT
20
01435-00610
BOLT
21
20Y-979-2231
DUCT
22
01435-00610
BOLT
23
20Y-979-2242
DUCT
24
01435-00610
BOLT
25
7827-10-1520
RESISTOR, 15OHM
26
01435-00820
BOLT
27
203-06-56230
BUZZER ASS'Y
28
01435-00610
BOLT
29
7834-30-2000
CONTROLLER
30
01435-00630
BOLT
31
7834-10-2003
CONTROLLER,PUMP
31
7834-10-2002
CONTROLLER,PUMP
31
7834-10-2001
CONTROLLER,PUMP
31
7834-10-2000
CONTROLLER,PUMP
32
01435-00630
BOLT
33
20Y-06-24420
CONTROLLER,WIPER
33
20Y-06-23650
CONTROLLER,WIPER
34
01435-00630
BOLT
35
20Y-06-24110
WIRING HARNESS
36
20Y-06-24220
SHEET
37
08051-00801
CLIP
38
20Y-06-23521
LOCK
39
01435-00820
BOLT
40
7834-87-3000
PANEL
41
20Y-06-24141
BRACKET
42
01252-40410
BOLT
42
01023-10408
SCREW
42A
01601-20410
WASHER
42B
01641-20405
WASHER
43
01010-50614
BOLT
44
01643-30623
WASHER
45
20Y-06-21231
WIRING HARNESS
46
08034-00519
BAND
46
08034-00414
BAND
47
01010-51020
BOLT
48
01643-31032
WASHER
Выбрано товаров: 57
