Запчасти Komatsu PC200LC-6H ОХЛАЖД-Е (РАДИАТОР) (С КОНДИЦИОНЕРОМ)(№9999-9) СИСТЕМА ОХЛАЖДЕНИЯ

1

20Y-03-21710

CORE ASS'Y

2

20Y-03-22110

CAP

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

203-03-41410

HOSE

6

20Y-03-11330

CLIP

7

01010-81025

BOLT

8

01643-31032

WASHER

9

20Y-03-21480

SEAL

10

20Y-03-21490

SEAL

11

20Y-03-21750

BRACKET

12

20Y-03-21760

BRACKET

13

20Y-03-21320

SEAL

14

20Y-03-21720

OIL COOLER ASS'Y

15

20Y-03-21330

SEAL

16

01010-81225

BOLT

17

01643-31232

WASHER

18

20Y-03-21430

SEAL

19

20Y-03-21141

NET

20

01434-10616

BOLT¤ WING

21

01643-30823

WASHER

22

20Y-03-21430

SEAL

23

20Y-03-21631

SHROUD

24

01435-20816

BOLT

25

20Y-03-14110

SEAL

26

20Y-03-21380

PLATE

27

01010-81025

BOLT

28

01643-31032

WASHER

29

20Y-979-2831

BRACKET

30

01010-51025

BOLT

31

01643-31032

WASHER

32

20Y-979-2841

BRACKET

33

01010-51025

BOLT

34

01643-31032

WASHER

35

20Y-979-2820

BRACKET

36

01010-51025

BOLT

37

01643-31032

WASHER

38

20Y-03-21270

SEAL

39

20Y-03-21260

SEAL
