Запчасти Komatsu PC200LC-6 ГИДР. БАК. (RTATION РУКОЯТЬ)(№9-) ГИДРАВЛИКА

Схема запчастей Komatsu PC200LC-6 - ГИДР. БАК. (RTATION РУКОЯТЬ)(№9-) ГИДРАВЛИКА
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
16
17
18
19
20
21
22
23
24
24A
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42A
43
44
44
45
45
46
47

Артикул

Название

Примечание

Количество

1

TANK

|1

TANK

|1

TANK

2

203-60-31100

ELBOW ASS'Y

|2

208-04-19130

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

209-62-57430

TEE

7

07002-02434

O-RING

8

07236-10522

ELBOW

9

07002-02434

O-RING

10

07235-10315

ELBOW

11

07002-02034

O-RING

12

07236-10315

ELBOW

13

07002-02034

O-RING

14

07236-10210

ELBOW

15

07002-01423

O-RING

16

20Y-60-21510

ELEMENT

17

07069-25400

STRAINER

|17

206-60-41221

STRAINER

18

07069-05400

VALVE ASS'Y

|18

12R-60-11300

VALVE ASS'Y

19

07069-34075

SPRING

|19

20Y-60-21240

SPRING

20

20Y-60-22530

COVER

21

07000-15180

O-RING

|21

07000-05180

O-RING

22

01010-81230

BOLT

23

01643-31232

WASHER

24

7861-92-4210

SENSOR

24A

7861-91-4220

O-RING

25

01252-40612

BOLT

26

01641-20608

WASHER

|27

20Y-60-22550

STRAINER ASS'Y

27

20Y-60-21311

STRAINER

28

207-60-61150

ROD ASS'Y

29

20Y-60-21320

HOLDER

30

12R-60-11230

SPRING

31

203-60-61140

COVER

32

07000-15180

O-RING

|32

07000-05180

O-RING

33

01010-81225

BOLT

34

01643-31232

WASHER

35

17A-60-11310

CAP ASS'Y

36

20Y-60-21470

ELEMENT

37

20Y-60-21460

NECK

38

20Y-60-21340

GASKET

|38

205-60-66211

GASKET

39

01252-70516

BOLT

|39

01220-40516

SCREW

40

01601-20513

WASHER

41

07285-00155

CLIP

42

20Y-60-21190

TUBE

|42

07270-61512

TUBE

42A

205-00-73360

PLATE¤ OPERATING

43

20Y-60-22561

COVER

44

01220-40412

SCREW

45

20Y-60-22540

PLATE

46

01010-81635

BOLT

47

01643-31645

WASHER

Выбрано товаров: 61
