Запчасти Komatsu PC200LC-6 MULTI PATTERN КЛАПАН (WAY) (MULTI КЛАПАН) ГИДРАВЛИКА

|1

20T-62-74900

VALVE ASS'Y

1

BODY

2

SHAFT

|2

SHAFT

3

20T-62-74930

LEVER

4

20T-62-74940

BRACKET

5

09822-00810

PLATE¤ OPERATING,SELECT VALVE

|5

20T-62-74950

PLATE

6

07000-13025

O-RING

|6

07000-03025

O-RING

7

07043-00108

PLUG

8

07000-13032

O-RING

|8

07000-03032

O-RING

9

07003-12733

GASKET

10

01010-80616

BOLT

|10

01010-50616

BOLT

11

01643-30623

WASHER

12

01434-10620

BOLT¤ WING,WING

13

01010-80616

BOLT

|13

01010-50616

BOLT

14

01643-30623

WASHER

15

01010-80825

BOLT

|15

01010-50825

BOLT

16

01643-30823

WASHER

17

07238-10210

CONNECTOR

18

20Y-62-25690

NIPPLE

19

201-60-11390

O-RING

20

20Y-62-19560

O-RING

21

20Y-62-25631

BRACKET

22

01010-81230

BOLT

|22

01010-51230

BOLT

23

01643-31232

WASHER
