Запчасти Komatsu PC200EN-6K ЦИЛИНДР КОВША(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K1902

CYLINDER ASS'Y,BUCKET

|1

21P-63-03330

CYLINDER ASS'Y

1

21P-63-72740

CYLINDER

2

21P-63-72720

ROD,PISTON

3

707-27-11920

HEAD,CYLINDER

4

707-36-11770

PISTON

5

01310-01216

SCREW

6

07000-15070

O-RING

7

707-35-90360

RING

8

01010-81675

BOLT

9

01643-51645

WASHER

10

144-63-94170

SEAL,DUST

11

07179-13089

RING,SNAP

12

707-51-75030

PACKING,ROD

13

707-51-75630

RING,BUFFER

14

07000-15100

O-RING

15

707-35-91130

RING,BACK-UP

16

707-52-90500

BUSHING

17

707-44-11180

RING,PISTON

18

707-39-11110

RING,WEAR

19

707-44-11911

RING

20

707-76-70370

BUSHING

21

20Y-70-23220

SEAL,DUST

|21

21K-70-12180

SEAL,DUST

22

707-76-70230

BUSHING

23

07145-00070

SEAL,DUST

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

21P-63-K2141

TUBE

27

707-88-99110

BAND

28

21P-63-K8560

BRACKET

29

07282-02288

CLAMP

30

01010-81020

BOLT

31

01643-31032

WASHER

32

01010-81035

BOLT

33

01643-31032

WASHER

34

01010-80850

BOLT

35

707-87-12830

ELBOW

36

07000-13025

O-RING

37

01643-50823

WASHER

38

07000-13030

O-RING

39

01010-81080

BOLT

40

01643-51032

WASHER
